Technoplat 2000 is a high-performance automatic wrapping station in the field of end-of-line packaging. The design, the choice of materials and the implementation of software dedicated to putting this baler online have followed rigorous quality and safety standards.
| Table diameter | mm | 1800 |
| Maximum capacity | kg | 1500 |
| Table rotation speed | rpm | 5÷15 |
| Adjustable roller speed | m/min | 8÷11 or 12÷15 |
| Car up-down speed | m/min | 1.5÷5.5 |
| Maximum pallet dimensions (LxW) | mm | 1200×1000 |
| Maximum product height | mm | 2400 std. 2800/3100 opt. |
| Working height | mm | 400÷550 |
| Cart type | PDS, PVS | |
| Film tensioner | adjustable from the panel | |
| Pre-stretched film | up to 250% std (PDS), variable 150-400% (PVS) | |
| Fork placement | front and rear | |
| Supply voltage | V | 230 V 1Ph + N |
| Power frequency | Hz | 50/60 |
| Installed power | kW | 4 (PDS) 4.3 (PVS) |
| Maximum coil dimensions | mm | 500×300 |
| Maximum coil weight | kg | 20 |
| Film thickness | μm | 17÷35 |
