Main technical characteristics

• Correct version
• AISI 304 stainless steel structure
• 7” multilingual color touch screen interface
• Built-in loading belt, with automatic product management.
• New welding wheel heating system that allows reduced energy consumption and precise temperature control.
• Extraction and sealing of the film using three pairs of wheels (1 cold for film extraction, 1 hot for film welding, 1 for film folding), the pair of cold rollers can be tilted to obtain perfect adhesion of the film.
• The transversal sealing system is Box Motion, thus allowing short and long containers to be made without penalizing production. Welding jaws with a special profile that allows for hermetic seals and greater product flow.
• The entry and exit conveyors of the sealing system are equipped with edge-sealed belts that comply with food contact regulations.
• Motorized expansion spool shaft, spool centerer and compensation brake. Maximum reel width of 600 mm
• Photocell for printing centering
• Pneumatic pad to eliminate excess air, to avoid the swelling effect
• Lexan protections, with natural anodized aluminum frame, openable and equipped with safety sensors
• Teleservice
• Standard speed 60 pieces/minute
• Power supply: three-phase 400 + Neutral – 50Hz
• Consumption: 14 Amps – 6 Bar (continuously)

Main options

• Left version
• Eurohole
• Loading conveyor belt for manual product handling
• Function “No product – No bag”
• Micrometric dosage of liquids (alcohol, anti-mold)
• Gas inflation system (MAP)
• Gas analyzer
• Double film feeding with automatic reel change
• Automatic rejection of non-compliant products
• Structure on wheels
• Printer / Label Maker

DIMENSIONS: 4500mm x 1200mm Height 1600mm

WEIGHT: 800Kg
