GEBO

The “smallest of the family” GEBO packaging machine is an electronic machine with 3 continuous servomotors driven by an intelligent motion controller.

Ideal for small and medium productions, it is designed to meet the needs of the food and non-food industry. This packaging machine, with a rotary “cutting and sealing” system, is equipped with a state-of-the-art PLC for temperature control, integrated diagnosis, memorization of different formats (recipes) and a multilingual multifunction touch screen.

The structure, made entirely of stainless steel, allows easy placement in food, medical and humid environments. The electronics are located inside the machine frame, easily accessible but protected against humidity and infiltration. Various accessories can be added to the basic model.

The machine is manufactured in accordance with the current CE Machinery Directive and for use in food handling environments.

Main technical characteristics

  • Left/right version (products flow from right to left)
  • Cantilever structure made of AISI 304 stainless steel
  • 7” color touch screen interface
  • Rotary cutting and sealing unit
  • Average packaging speed: 100 packages/minute
  • Integrated 2000mm manual loading conveyor
  • 3 pairs of welding wheels (1 cold for pulling film, 1 hot for welding film, 1 for folding film)
  • Single-axis film reel holder, with manual centering and fixing system
  • Maximum reel width of 420 mm
  • Automatic opening of the welding wheels when the machine stops
  • Stainless steel fixed film former
  • Integrated 800 mm output conveyor equipped with a belt compatible with food contact.
  • Transparent polycarbonate safety protectors, openable and equipped with safety sensors.
  • Printer ready signal, manageable from the touch screen and storable to create a recipe program
  • Electronics located inside the machine frame, easily accessible and protected from humidity and infiltration.
  • Power supply: three-phase 400 + Neutral + Ground – 50Hz



Main options

  • Eurohole
  • Micrometric dosage of liquids (alcohol, anti-mold)
  • Gas inflation
  • Batch, code and date printer/labeler
  • Automatic feeding systems.
  • Double axis film reel holder
  • Registered wrapper to automatically adjust package length
  • Adjustable film former
  • No product – No bag function
  • Gusset packaging
  • Removing excess air from the package
  • Structure on wheels
  • Teleservice device
