FLOW LAGUZ

FLOW LAGUZ Let yourself go! The beginning of something new. A complete renovation!

This machine has been improved from every point of view, with a new design and a long list of new connectivity and security features. The mechanical and electronic units are located at the rear of the packaging machine.

The Flow Laguz is the version with top sealing of our HFFS packaging machines, with the film reel located in the lower part of the machine and the longitudinal sealing carried out in the upper part of the package, which makes it perfect for products that are difficult to transport, as it allows the product to enter the machine already resting on the film. It stands out for its cantilever structure, its easy accessibility and maintenance, and its safety and hygiene elements. It is made entirely of AISI 304 stainless steel. FLOW LAGUZ

Its durability, easy operation, reliability, versatility and flexibility in changing formats make it a machine that adapts perfectly to any packaging need, for any application.

FLOW LAGUZ All machine functions are managed by sophisticated but easy-to-use electronics. The supply of the product is carried out using a conveyor belt that is supplied with the machine. This packaging machine can be integrated with any loading automation and end-of-line unit, even for extremely high production volumes.

Compatible Films: All heat sealable and machinable films, such as polypropylene, lightweight coupled film, cold seal. Single/double seal coupled film.

FLOW LAGUZ Crestpack

FLOW LAGUZ – OMRON electronic components and motorization

Types of packages:

  • Standard pillow bags
  • Pillow bags with side closure
  • Pillow bags with Euroslot
  • Pillow bags with zipper closure
  • Gusset bags
  • Gusset bags with side sealing
  • Bags with gusset and zipper closure
  • Easy-open gusseted bags
  • Easy Open and Euroslot gusseted bags



Main features

  • Machine made of stainless steel.
  • Right/left version.
  • Longitudinal sealing system with three pairs of rollers, two of which are heated, to ensure smooth unrolling of the film and perfect sealing.
  • 2 meter long feeding platform.
  • This durable and reliable standard machine is available with a coil width of 600 mm.
  • Adjustment of the length of the package depending on the length of the product.
  • Function “No product, no bag” and “security of the product incorrectly placed in the sealing clips” function.
  • Touch screen to adjust machine parameters, perform diagnostics and obtain information on machine status.
  • Storage of the parameter for creating programs.



Main options

  • Long Dwell Cross Sealing Unit
  • Feeding platforms of different types and lengths
  • Photocell to center the molded film
  • Gas blowing system
  • Different automatic feeding systems
  • Micrometric dosage of liquids (alcohol, anti-mold)
