| Height of motorized side guide tapes | mm | 50 std. 75-115 opt. (65 A) / 115 std. 75 opt. (80 A) |
| Box drag speed | m/min | 22 |
| N. 2 taping heads (upper and lower) | opt | |
| Maximum box dimensions (LxWxH) | mm | ∞ x 650 x 650 (65 A) / ∞ x 800 x 800 (80 A) |
| Supply voltage | V | 400 V 3Ph + N + T |
| Power frequency | Hz | 50 |
| Installed power | kW | 0.5 |
| Compressed air consumption | Nl/min | 142 (65 A) / 164 (80 A) |
| Working pressure | bar | 5 |
