Type of strap: Polypropylene (PP) and Polyester (PET)
Usable strap: Width from 8 to 19 mm thickness from 0.60 to 1 mm
Strap tension: Up to 700 kg
Strap welding: By welding or vibration
Launch and recovery speed: from 2.4 to 5.5 m/sec
Tension speed: 0.25 m/sec
Welding cycle time: From 1.2 to 3 seconds depending on tension
Supply voltage: 220/400 V AC — 50/60 Hz
Installed electrical power: 3 kW
Arc: Standard dimensions: 1510×1510 mm; Custom arches are made
Coil holder: Interior diameter 390/405 mm, width 150/160 mm
Optional
Load pressure device
Compaction device for 4 sides
Corner applicator
